BAKFlip MX4 Drain Tubes – Factory Replacement Parts
Our factory drain tubes are precision-engineered to restore full water-channeling performance on your BAKFlip MX4 tonneau cover. Each tube routes moisture away from the bed rails through the same OEM pathways installed at the factory, preventing pooling and protecting your cargo.
We built these replacement channels with the same durable PVC compound used in original production, ensuring consistent flex performance across temperature extremes. The tubes attach to existing mounting points without modification, giving you factory-grade drainage in minutes.
Drain tube specifications
Materials & Construction
We manufacture these bakflip mx4 drain tubes from industrial-grade PVC selected for its long-term flexibility and chemical resistance. The compound maintains shape memory across winter freeze-thaw cycles and summer heat, preventing the brittleness that causes aftermarket tubes to crack at bend points.
Each tube wall is extruded at 2mm thickness to balance flex with crush resistance. The internal diameter matches factory specifications exactly, so water flows at the intended rate without restriction. Our parts and accessories undergo the same quality testing as original equipment, including 500-hour UV exposure and repeated compression cycles to verify performance longevity.
Installation Process
Installation requires no special tools or modifications to your tonneau cover. You’ll locate the drain tube mounting points along the inside edge of each bed rail, where the original tubes connected to the panel hinge channels.
Remove the old tubes by gently pulling them free from the mounting clips. Route the new tubes through the same pathway, pressing firmly into each clip until you hear a snap. The pre-cut lengths eliminate the need for trimming, and the factory bend points align naturally with rail contours. Total installation time is typically under 15 minutes for both sides.
Performance & Water Management
These drain tubes work as part of the MX4’s integrated water management system. Rain and snowmelt that reach the panel seams flow into the drain channels molded into each hinge, then exit through these tubes at designated drainage points near the cab and tailgate.
Proper tube function prevents water from pooling on top of closed panels or seeping into the bed at rail edges. We recommend inspecting tubes twice yearly and replacing them at the first sign of cracking or reduced flex, typically after three to five years of exposure depending on your climate.
Essential BAKFlip MX4 Maintenance Parts
Rated 4.8 by verified buyers
BAKFlip MX4 Drain Tube Questions
We recommend inspecting your drain tubes every six months and replacing them when you notice reduced flexibility, visible cracks, or water pooling along the bed rails. Most tubes last three to five years depending on UV exposure and temperature extremes in your region.
If you park outdoors year-round in high-UV climates, expect to replace tubes closer to the three-year mark. Garage-stored covers in moderate climates often reach five years or more before replacement becomes necessary.
Yes, these drain tubes fit all BAKFlip MX4 tonneau covers regardless of your truck’s make, model, or bed length. The MX4 uses a universal drain channel design across Ford, Chevy, Ram, Toyota, Nissan, and GMC applications.
The only compatibility concern is verifying you own an MX4 model specifically—other BAKFlip series like the G2 or F1 use different drain tube designs and mounting methods.
No special tools are required for installation. The tubes press into existing mounting clips by hand, and you’ll use the same hardware already installed on your tonneau cover.
Most owners complete the job using only their hands to route the tubes and press them into the clips. A flashlight helps when working near the cab end of the bed rail where visibility is limited.
While the tubes are sold as a matched pair, you can technically replace just one side if the other tube is still functioning properly. We recommend replacing both tubes together to ensure balanced drainage performance and avoid mixing old and new materials with different flex characteristics.
Replacing both sides at once also prevents the need for a second installation session when the older tube eventually fails.
UV exposure is the primary cause of drain tube deterioration. Sunlight breaks down the PVC compound over years of exposure, leading to reduced flexibility and eventual cracking at bend points.
Extreme temperature cycling also contributes to wear—repeated expansion and contraction can stress the material where tubes curve around bed rail corners. Road salt and chemical exposure accelerate degradation in certain climates.
Properly functioning drain tubes route water away from bed rails without visible leaking at mounting points or panel seams. After a rain, you should see water exiting at designated drain points near the cab and tailgate, not pooling on top of closed panels.
If you notice water seeping into your bed along the rail edges or see moisture collecting on panel surfaces, inspect the tubes for cracks or disconnection from mounting clips.
These drain tubes are designed to work with the factory BAKFlip MX4 bed rail system and mounting hardware. If you’ve modified your rails or installed aftermarket mounting systems, verify that the drain channel pathways and clip locations match OEM specifications.
Non-standard rail modifications may require custom tube routing or additional hardware not included in this kit.
